Точка доступа Cisco AIR-CAP2602I-C-K9 (AIR-CAP2602I-C-K9)

Точка доступа Cisco AIR-CAP2602I-C-K9
Cisco Производитель: Cisco
Смотреть все модели
0 р.
Быстрый заказ
Наличие: уточняйте
Минимальный заказ: 10 000 руб.

Минимальный заказ: 10 000 руб.

Тендеры

Принимаем участие и помогаем нашим клиентам выигрывать тендеры и поставлять требуемую продукцию!

Гарантия

На всё сетевое и серверное оборудование предоставляется гарантия до 3-х лет, в том числе на снятые с производства позиции.

Описание Точка доступа Cisco AIR-CAP2602I-C-K9

Беспроводная точка доступа CISCO AIR-CAP2602I-R-K9 — это устройство для объединения компьютеров в единую беспроводную сеть. Если Вы устали мучиться с огромным количеством кабелей, которые нужно прокладывать через стены и потолки, чтобы объединить компьютеры в обычную проводную сеть, то точка доступа CISCO AIR-CAP2602I-C-K9 как раз для Вас!

Технические характеристики:

Model info: AIR-CAP2602E-C-K9
Product DescriptionCisco Aironet 2600 Series Access Points with External antennas
Devide TypeWireless Access point
Regulatory domainC regulatory domain
Supported wireless LAN controllers? Cisco 2500 Series Wireless Controllers
? Cisco Wireless Controller Module for ISR G2
? Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches		? Cisco 5500 Series Wireless Controllers
? Cisco Flex 7500 Series Wireless Controllers
SoftwareCisco Unified Wireless Network Software Release 7.2.110 or later.
Data rates supported? 802.11a: up to 54 Mbps
? 802.11g: up to 54 Mbps		? 802.11n on 2.4 GHz: up to 450Mbps
Maximum number of nonoverlapping channels5 GHz
? 802.11a:
? 20 MHz: 21
? 802.11n:
? 20 MHz: 21
? 40 MHz: 9		2.4 GHz
? 802.11b/g:
? 20 MHz: 3
? 802.11n:
? 20 MHz: 3
Antenna (purchase separately)? Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)? Cisco offers the industry's broadest selection of 802.11n antennas delivering optimal coverage for a variety of deployment scenarios
Interfaces? 10/100/1000BASE-T autosensing (RJ-45)? Management console port (RJ-45)
System memory? 256 MB DRAM? 32 MB flash
Power consumption (Power supply purchase separately)15 Watts(standard 802.af PoE)
IEEE standards? IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d
Security? 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA
? 802.1X		? Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
Extensible Authentication Protocol (EAP) types? EAP-Transport Layer Security (TLS)
? EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
? Protected EAP (PEAP) v0 or EAP-MSCHAPv2		? EAP-Flexible Authentication via Secure Tunneling (FAST)
? PEAP v1 or EAP-Generic Token Card (GTC)
? EAP-Subscriber Identity Module (SIM)
Frequency band and 20-MHz operating channelsA (A regulatory domain):
? 2.412 to 2.462 GHz; 11 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
? 5.745 to 5.825 GHz; 5 channels
C (C regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.745 to 5.825 GHz; 5 channels
D (D regulatory domain):
? 2.412 to 2.462 GHz; 11 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.745 to 5.825 GHz; 5 channels
E (E regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
H (H regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.150 to 5.350 GHz; 8 channels
? 5.745 to 5.825 GHz; 5 channels
I (I regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
K (K regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.620 GHz; 7 channels
? 5.745 to 5.805 GHz; 4 channels		N (N regulatory domain):
? 2.412 to 2.462 GHz; 11 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.745 to 5.825 GHz; 5 channels
Q (Q regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.700 GHz; 11 channels
R (R regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.660 to 5,805 GHz; 7 channels
S (S regulatory domain):
? 2.412 to 2.472 GHz; 13 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.700 GHz;, 11 channels
? 5.745 to 5.825 GHz; 5 channels
T (T regulatory domain):
? 2.412 to 2.462 GHz; 11 channels
? 5.280 to 5.320 GHz; 3 channels
? 5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
? 5.745 to 5.825 GHz; 5 channels
Z (Z regulatory domain):
? 2.412 to 2.462 GHz; 11 channels
? 5.180 to 5.320 GHz; 8 channels
? 5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
? 5.745 to 5.825 GHz; 5 channels
Environmental? Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)
? Nonoperating (storage) Altitude Test: 25?C, 15,000 ft.
? Operating temperature: -4 to 131°F (-20 to 55°C)		? Operating humidity: 10 to 90 % (noncondensing)
? Operating Altitude Test: 40?C, 9843 ft.
